RDS-1350
Analog Pure Power Amplifier, 2×1350W @ 8Ω
Analog Pure Power Amplifier, 2×1350W @ 8Ω
• 2U Custom Mold Panel Amplifier, Dual Channel
• Rated Power (8Ω/Channel): 2x1350W
• Rated Power (4Ω/Channel): 2x2700W
• Rated Bridged Power (8Ω): 2700W
• Frequency Response: 20Hz–20kHz
• Signal-to-Noise Ratio: >105dB
• Damping Factor: >400 (8Ω) (5Hz–1kHz)
• Input Sensitivity: 0.775V/26dB/35dB
• Input Impedance: 20kΩ (Balanced), 10kΩ (Unbalanced)
• Total Harmonic Distortion: <0.1%
• Slew Rate: 29V/μS
• Operating Voltage: AC 230V, 50/60Hz
• Protection Features: Power Protection, Thermal Power Control, Short-Circuit Protection, Overload Protection, DC Output Protection
• Dimensions: 482 × 89 × 366 mm
• Weight: Net Weight 23.37kg, Gross Weight 26.85kg
